Blue Sea Battery Bank Management Panel.

$301.99

~~$301.99~~ $301.99

Sold out

Shipping calculated at checkout.

Low stock: 1 left

Battery Bank: Dual Bank Dual Bank Triple Bank

Description

Blue Sea Battery Bank Management Panels

Models:

Dual Battery Bank Management Panel (32V DC): 8686-BSS
Triple Battery Bank Management Panel (12V/24V DC): 8693-BSS

These panels are designed to isolate engine and house circuits while allowing emergency cross-connect between isolated battery banks as needed. They protect sensitive electronics from voltage sags and spikes caused by engine cranking and are built to withstand demanding marine environments.

Key Features

Isolates engine circuit from house circuit for safe and effective operation
Emergency cross-connect option for isolated battery banks to enable starting emergency
Protects electronics from sags and spikes during engine starting
Robust, marine-grade construction
Multiple circuit positions for system scalability (4 for 8686-BSS, 11 for 8693-BSS)

Specifications Comparison

Feature	8686-BSS (Dual Bank)	8693-BSS (Triple Bank)
Positions	4	11
Nominal Voltage	12V DC, 24V DC	12V DC, 24V DC
Maximum Voltage	48V DC	32V DC
Continuous Rating	300A	350A
Intermittent Rating	500A (5 min)	525A (5 min)
Cranking Rating 10 sec	1500A	1000A
Cranking Rating 1 min	775A	750A
Dimensions (HxWxD)	7.50" x 4.50" x 3.25"	8.00" x N/A x 3.50"
Weight	1.85 lb (0.84 kg)	4.42 lb (2.00 kg)
