Furuno 001-507-030-00 NMEA2000 Micro Cable 2 Meter Female to Pigtail

Product Description

The Furuno NMEA2000 Micro Cable 2 Meter Female to Pigtail is a drop cable for NMEA 2000 marine networks. It provides a 2-meter length with a Micro straight female connector on one end and bare wire pigtail leads on the other for custom wiring to sensors or devices.

Product Overview

This cable connects Furuno marine electronics like transducers, radars, or displays to NMEA 2000 backbones, enabling real-time data sharing for navigation and instrumentation on boats. Its mid-length design fits installations needing extra reach without excess cable in consoles or panels for boating and fishing systems.

Key Specifications

• Length: 2 meters (approx. 6 feet 7 inches)

• Connector Type: Micro straight female to pigtail (bare ends)

• Data Interface: NMEA 2000 compliant

• Usage: Drop cable for backbone-to-device connections

Technical Specifications

• Pinout: Shield (bare), NET-S (red), NET-C (black), NET-H (white), NET-L (blue) following NMEA 2000 Micro standard

• Voltage: 9-16V isolated networks; light cable rated for low current draw (up to 1A per drop)

• Network Limits: Max 6m per drop, 78m total drops, 50 devices per backbone

• Ensures <1.5V drop in 12V systems for reliable marine communication

What's in the Box

• 2m NMEA2000 Micro Cable (female to pigtail)
