Furuno Multi Cable For TZTouchXL (NME0183 Out)

Product Description

The Furuno Multi Cable for TZTouchXL (NMEA0183 Out),  is an optional wiring harness for NavNet TZtouchXL multifunction displays. It provides NMEA 0183 output connectivity along with power distribution for external instruments, buzzers, and NMEA 2000 networks in marine electronics setups.

Product Overview

This multi cable integrates TZTouchXL chartplotters with legacy NMEA 0183 devices like GPS receivers, AIS, or autopilots on boats, enabling data sharing for navigation and alarms. It's essential for hybrid network installations in fishing or pleasure craft where older sensors connect to modern Furuno systems via the 14-wire SMP-11V connector.

Key Specifications

• Connector: SMP-11V (14-pin) to individual wires for flexible terminations

• Protocols: NMEA 0183 Tx (output), NMEA 2000 power, external buzzer

• Length: Compact harness design (exact unspecified, suited for console mounting)

• Compatibility: TZTouchXL series (TZT10X, TZT13X, TZT16X models)

Technical Specifications

• NMEA 0183 Output: TD-A (blue wire), TD-B (white wire), configurable baud rates (4800/9600/38400 bps)

• Wiring includes power (positive/negative), ground, and multi-device support

• Marine-rated for reliable data transmission in saltwater environments

• Pricing around $25 USD for easy plug-and-play installation

What's in the Box

• TZTouchXL Multi Cable (NMEA0183 Out) with 14 wires
