Lumitec Kraken Dock Light 10-30vDC Bronze Housing.
Couldn't load pickup availability
Description
Description
Lumitec Kraken Dock Lighting System
Model Numbers:
-
101636 — Dual Color Blue/White
-
101637 — Spectrum RGBW Full-Color
Overview:
The Lumitec Kraken Dock Lighting System is engineered to deliver robust, high-output underwater lighting suitable for commercial applications and larger residential installations. Powered by the field-proven SeaBlazeX2 platform, each individual Kraken underwater light produces more than 6,000 lumens of white output. The system is controlled via a single Kraken command box capable of managing up to five lights. Complementary lighting options like Nautilus Piling and Scallop Pathway Lights allow complete walkway and deck illumination, all controllable via smartphone, tablet, or connected device. The system balances power, versatility, and ease of installation, making it ideal for demanding marine lighting needs.
Key Features:
-
Over 6,000 lumens of measured white light output per underwater light.
-
Available in dual-color white/blue or vivid full-color RGBW output.
-
Operates on 10-30 V DC with 60W power consumption (5A @ 12V, 2.5A @ 24V).
-
IP67 rated for submersible marine performance.
-
Timed toggled protocol enabled for advanced light control.
-
Not compatible with third-party dimmers.
-
Compact size with 3.94" diameter and 2.1" depth.
-
Mounting hole diameter of 1/2" for secure installation.
-
Operating temperature range from -31°F to 131°F (-35°C to 55°C).
-
Color rendering index (CRI) of 70+.
-
No color match commitment.
-
Designed and manufactured to meet commercial-grade ruggedness and residential versatility.
Specifications Comparison
| Feature | 101636 Dual Color Blue/White | 101637 Spectrum RGBW |
|---|---|---|
| Lumens (White) | 6000 | 6000 |
| Voltage | 10-30 V DC | 10-30 V DC |
| Current Draw 12 V | 5 A | 5 A |
| Current Draw 24 V | 2.5 A | 2.5 A |
| Rated Power | 60 W | 60 W |
| Correlated Color Temperature | 6500 K | 6500 K |
| Color Rendering Index (CRI) | 70+ | 70+ |
| Mounting Hole Diameter | 1/2" | 1/2" |
| Depth | 2.1 in (5.33 cm) | 2.1 in (5.33 cm) |
| Diameter | 3.94 in (8.86 cm) | 3.94 in (8.86 cm) |
| Timed Toggled Protocol | Yes | Yes |
| Third Party Dimmer Compatible | No | No |
| Color Match Commitment | No | No |
What’s in the Box:
-
Lumitec Kraken underwater lights (specific model, individual sold separately)
-
Kraken command box (sold separately) powers up to 5 lights
-
Mounting hardware and installation instructions (per light)
