Maxwell SP5104 12v Reversing Solenoid For RC8-8, RC10, RC12

Product Description

The Maxwell SP5104 is a 12V reversing solenoid pack for RC8-8, RC10, and RC12 windlasses.

Product Overview

This 3-pole heavy-duty solenoid enables dual-direction motor control via remote panels, footswitches, or AutoAnchor systems on larger Maxwell windlasses. It handles over 200 amps continuous for reliable anchoring performance.

Key Specifications

• Voltage: 12V DC for series wound (SW) motors.

• Current rating: 200+ amps continuous.

• 3-pole ignition-protected design.

• Waterproof enclosure (dry install recommended).

Technical Specifications

• Dimensions: 5" x 5" x 3" (127x127x76mm).

• Replaces P19045 solenoid.

• CE approved for marine safety.

• Suits 1000-1200W windlass motors.

What's in the Box

• One SP5104 12V reversing solenoid pack.
